  • Schematic Image 966001001
  • Genesis II S-310 NG SS US/CA (2020)
  • 966001001

Pièces additionnelles

Séquence Partie # La description Voir en ligne
1 67088 Thermometer, '18
2 66049 Thermometer bezel, Genesis
3 66513 Logo plate, SS
4 66061 Lid bumpers (qty 2)
4 66438 Lid hardware, Genesis/Searwood
4 67368 Lid assembly, Genesis II 3 burner, SS, '19
5 66831 Handle bezel, Genesis II LX, '17
6 66417 Lid handle, Genesis II LX 340
7 66044 Warming rack, Genesis II E-310
8 66802 Set of cooking grates, SS, 7 mm, Genesis II LX 340 Voir maintenant162,99 $
9 66795 Stainless steel flavorizer bars, Genesis II LX 340 (qty 5)
10 67491 NG main burner tube kit, Genesis II 3 burner, '19
11 69319 Igniter electrode, yellow wire, 23"
11 69320 Igniter electrode, black wire, 32"
11 69321 Igniter electrode, green wire, 42"
12 66685 Heat deflector, SS, Genesis II LX 340 (qty 3)
13 69284 Warming rack bracket set
14 66029 Burner tube clamp set, Genesis II E/SE series (qty 2)
15 67376 LHS fixed table, Genesis II, '19
15 68582 Hardware for fixed table, Genesis II '19
16 66824 Hardware for cookbox, Genesis II/II LX
16 67407 Cookbox, Genesis II 310/315, '19
16 66822 Hardware, manifold, Genesis II LX
17 66357 Clip for ignition wire routing, round set (qty 2)
18 67460 NG manifold assembly, Genesis II 310/315, '19
19 66028 Bottom tray rails, Genesis II E/SE series
20 66036 Grease tray, Genesis II E-310/340
21 67420 LHS frame connector, Genesis II, '19
22 66229 Top trim for control panel, SS, Genesis II/LX 300 series
23 66254 Control panel assembly, Genesis II E-310
24 69283 Igniter/momentary switch, Genesis II '20
25 69317 Igniter button wire, 3 burner Genesis II
26 66047 Control knob set, Genesis II 310/610 (qty 3)
27 6415 Aluminum drip pans - small (10 pack) Voir maintenant13,99 $
28 93305 Aluminum catch pan kit
29 67421 Wire rack/Catch pan holder
30 67422 Retainer for catch pan w/label
31 67447 Set of bushings for wire rack, qty. 4
32 69325 Wire clip management 3 pack
32 67390 Front frame, Genesis II 310, '19
33 67066 Caster insert kit
33 67067 Casters (qty 2)
34 66066 Bottom slat mounting bracket set, Genesis II E/SE series (qty 2)
35 66068 Bottom slat set, Genesis II E/SE series (qty 2)
36 66438 Lid hardware, Genesis/Searwood
37 67384 RHS fixed table, Genesis II, '19
37 68582 Hardware for fixed table, Genesis II '19
38 67334 iGrill cover w/snap
39 66456 Rear frame top trim, Genesis II LX 340
40 67391 Rear frame, Genesis II 310, '19
41 66218 RHS frame connector, Genesis II E/SE series
42 66679 Hardware, tank panel buttons
42 69331 Front/igniter module mounting panel, Genesis II AU/NZ
43 67455 Main corrugated gas line, Genesis II, '19
44 69308 Igniter kit, Genesis II 310/315 '20
44 69314 Igniter module
45 69316 Ground wire, blue, 24.25"
46 66212 Bulkhead assembly, Genesis II E-210/310
47 99263 NG hose w/quick disconnect - 3/8" hose Voir maintenant88,99 $
48 67654 Wheel insert kit, Genesis II, '19
49 67445 Wheel w/insert, Genesis II, '19
50 66533 Match holder assembly, Genesis II LX 240/340
51 66251 Axle w/hardware, Genesis II E/SE series
410 40441802 Literature kit, Genesis II 310/410 NG, US/CA
470 73052 Hardware bag F - igniter, NG
470 73417 Hardware bag B, cookbox
470 66679 Hardware, tank panel buttons
470 73054 Hardware bag C - frame
470 73432 Hardware bag D, trim
470 73044 Hardware kit Genesis II 300 series NG '20
470 73395 Hardware bag A, frame/wheel
470 73433 Hardware bag E, fixed table
510 6415 Aluminum drip pans - small (10 pack) Voir maintenant13,99 $
510 7211 iGrill Pro Meat Probe Voir maintenant23,99 $
510 7599 Griddle, Genesis II 300/400/600 series
510 7652 Rotisserie, Genesis II/LX 200/300 series
510 7130 Premium grill cover, Genesis II/LX 300, Genesis E/S 300
510 7212 iGrill Pro Ambient Probe
510 7620 Stainless steel flavorizer bar set (Qty 5) Genesis 300 series '11
510 8854 Sear grate, Genesis II/LX 300/400/600
510 7204 Weber iGrill 3
510 7516 Weber Handle Light, 2015-2019
510 7621 Porcelain enamel flavorizer bar set (Qty 5), Genesis 300 series '11 Voir maintenant72,99 $
