A
|
38000
|
Assembly guide for 4 burner Summit Gold/Platinum
|
|
|
E
|
42775
|
Hardware kit, Summit Platinum, stainless steel
|
|
|
A
|
38056
|
Literature kit for 4 burner Summit LP, USA
|
|
|
A
|
38008
|
Owners manual for 4 burner Summit LP, USA
|
|
|
1
|
88206
|
Hardware for lid assembly
|
|
|
2
|
60393
|
Thermometer w/o tab
|
|
|
2
|
67088
|
Thermometer, '18
|
Shop Now$19.99
|
|
3
|
67717
|
Bezel for Genesis/Summit, '07
|
|
|
4
|
41738
|
Swing-up basket for Summit, stainless steel
|
|
|
5
|
41231
|
Cook grate, Summit Platinum 4 burner, ss rod (Qty 1)
|
|
|
6
|
9896
|
Set of flavorizer bars for 4 burner Summit A/B
|
|
|
7
|
84106
|
Flat washer, 1/4", nylon, natural
|
|
|
7
|
85973
|
Bolt, 1/4-20 for manifold, stainless steel
|
|
|
8
|
97438
|
1/4-20 hex nut, stainless steel
|
|
|
9
|
42322
|
Igniter kit for Summit B/B4
|
|
|
10
|
85660
|
Burner tube kit, Summit 4 burner Silver/Gold/Platinum A/B
|
|
|
10
|
67663
|
Crossover tube, (qty 1)
|
|
|
11
|
85660
|
Burner tube kit, Summit 4 burner Silver/Gold/Platinum A/B
|
|
|
12
|
42542
|
Screw, 1/4-20x1/2 phillips trushead, black
|
|
|
13
|
82626
|
LP manifold for 4 burner Summit A/B
|
|
|
14
|
42322
|
Igniter kit for Summit B/B4
|
|
|
15
|
42322
|
Igniter kit for Summit B/B4
|
|
|
16
|
42322
|
Igniter kit for Summit B/B4
|
|
|
17
|
42322
|
Igniter kit for Summit B/B4
|
|
|
17
|
42053
|
Ignition switch, red button, for Summit Silver/Gold
|
|
|
18
|
60875
|
10-24x1/2 screw, stainless steel
|
|
|
18
|
84107
|
Plastic washer, natural, for control panel and mounting bracket
|
|
|
19
|
42772
|
Control knob, Summit Platinum, large
|
|
|
20
|
41703
|
Mounting clip for control panel
|
|
|
21
|
42118
|
Ignition decal for front panel
|
|
|
24
|
196
|
Hardware for trim pieces
|
|
|
25
|
84106
|
Flat washer, 1/4", nylon, natural
|
|
|
26
|
60775
|
1/4-20 x 1/2 hexhead bolt, stainless steel
|
|
|
27
|
60475
|
Bracket for LHS swing table
|
|
|
30
|
99240
|
Door plugs and bushings
|
|
|
31
|
82699
|
Bottom panel, Summit Platinum 4 burner, '05
|
|
|
32
|
67762
|
Hardware kit for bottom panel
|
|
|
33
|
99241
|
Caster w/insert
|
Shop Now$8.99
|
|
34
|
60463
|
LHS door replacement, Summit 4 burner, '05
|
|
|
35
|
81495
|
Screw 10-16x.750, philips pan head sems
|
|
|
36
|
4086935
|
Plastic plug for control panel, .250
|
|
|
37
|
82759
|
Door stop, Summit, SS
|
|
|
38
|
43849
|
Door handles w/screws, stainless steel
|
|
|
39
|
78714
|
Hinge rod for Summit doors, '05
|
|
|
40
|
60462
|
RHS door replacement, Summit 4 burner, '05
|
|
|
41
|
88206
|
Hardware for lid assembly
|
|
|
42
|
82702
|
Logo replacement, Summit Platinum, '05
|
|
|
42
|
82691
|
Lid assembly, Summit Platinum 4 burner, SS, '05
|
|
|
43
|
84102
|
Hexhead screw, 1/4-20 x 3.25, SS
|
|
|
43
|
60873
|
1/4 stainless steel washer
|
|
|
44
|
9896
|
Set of flavorizer bars for 4 burner Summit A/B
|
|
|
45
|
41836
|
Warming rack for 4 burner Summit, stainless steel
|
|
|
46
|
82707
|
Cookbox, Summit Platinum A4/B4, '05 - discontinued
|
|
|
47
|
42322
|
Igniter kit for Summit B/B4
|
|
|
48
|
85660
|
Burner tube kit, Summit 4 burner Silver/Gold/Platinum A/B
|
|
|
49
|
42243
|
Heat shield, Summit
|
|
|
50
|
42057
|
Corrugated LP/NG gas line for Summit Silver/Gold, stainless steel
|
|
|
51
|
84110
|
Wing nut, 10-24, type D, stainless steel
|
|
|
51
|
84107
|
Plastic washer, natural, for control panel and mounting bracket
|
|
|
51
|
82686
|
Bulkhead assembly, Summit Platinum LP, w/side burner
|
|
|
52
|
42322
|
Igniter kit for Summit B/B4
|
|
|
53
|
65941
|
QCC1 hose and regulator, Gold, Platinum, Silver
|
Shop Now$45.99
|
|
54
|
41933
|
Bottom tray for 4 burner Summit, black
|
|
|
55
|
99253
|
Catch pan holder (packaged)
|
Shop Now$22.99
|
|
56
|
6415
|
Aluminum drip pans - small (10 pack)
|
Shop Now$10.99
|
|
57
|
93305
|
Aluminum catch pan kit
|
Shop Now$13.99
|
|
61
|
82718
|
Hardware for tank scale
|
|
|
62
|
987101
|
Replacement hubcaps (pack of 3)
|
|
|
64
|
87901
|
Wing nut 1/4-20 inch. Black.
|
|
|
64
|
99243
|
Tank scale
|
|
|
64
|
92177
|
Tank scale lock bracket
|
|
|
65
|
82712
|
Right trim, Summit Platinum B/C/D, '05
|
|
|
66
|
80313
|
Tank glide buttons
|
|
|
67
|
60476
|
Bracket for RHS swing table
|
|
|
68
|
42040
|
Match holder
|
|
|
69
|
41559
|
Rear panel for Summit 4 burner, '05
|
|
|
70
|
99240
|
Door plugs and bushings
|
|
|
410
|
38000
|
Assembly guide for 4 burner Summit Gold/Platinum
|
|
|
410
|
38056
|
Literature kit for 4 burner Summit LP, USA
|
|
|
410
|
38008
|
Owners manual for 4 burner Summit LP, USA
|
|
|
470
|
42775
|
Hardware kit, Summit Platinum, stainless steel
|
|
|
470
|
82718
|
Hardware for tank scale
|
|
|
470
|
80313
|
Tank glide buttons
|
|
|
480
|
42322
|
Igniter kit for Summit B/B4
|
|
|
510
|
9976
|
Rotisserie for 4 burner Summit
|
|
|
510
|
7516
|
Weber Handle Light, 2015-2019
|
|
