A
|
56693
|
Instruction sheet, Ranch '10
|
|
|
A
|
57884
|
Charcoal Owners Guide USA '15
|
|
|
A
|
54777
|
Charcoal owners guide, US
|
|
|
D
|
87430
|
Hardware bag for Ranch Kettle
|
|
|
1
|
40260301
|
Handle kit w/o shield, 6" gray
|
|
|
2
|
40260301
|
Handle kit w/o shield, 6" gray
|
|
|
3
|
40260301
|
Handle kit w/o shield, 6" gray
|
|
|
4
|
87605
|
Flat washer 1/4 inch
|
|
|
4
|
87401
|
Screw 1/4-20 x 5/8" slotted truss head, zinc
|
|
|
5
|
87925
|
1/4-inch aluminum flat washer
|
|
|
5
|
87401
|
Screw 1/4-20 x 5/8" slotted truss head, zinc
|
|
|
5
|
87412
|
Aluminum washer .875 x .319 x .125 inch
|
|
|
6
|
78105
|
Lid damper for 37.5" Ranch Kettle, black
|
|
|
7
|
87505
|
Acorn nut 1/4-20 inch
|
|
|
8
|
1309
|
Hex nut 1/4 x 20 inch Keps nut
|
|
|
8
|
90062
|
Lid Assembly, Ranch Kettle, black
|
|
|
9
|
80645
|
Hinged cooking grate, stainless steel, Ranch, '10
|
Shop Now$363.99
|
|
10
|
66912
|
Charcoal grate, Ranch Kettle
|
Shop Now$184.99
|
|
11
|
85722
|
Wire lid support for Ranch Kettle
|
|
|
12
|
87415
|
Flat washer 5/16 inch, SAE
|
|
|
13
|
87414
|
Hex nut 5/16-18 inch, zinc
|
|
|
14
|
85723
|
Lid roller for Ranch Kettle, qty. 1
|
|
|
15
|
87412
|
Aluminum washer .875 x .319 x .125 inch
|
|
|
16
|
87416
|
Washer split lock 5/16 inch, zinc
|
|
|
17
|
63159
|
Bowl for the 37.5" Ranch Kettle, black (Manufactured in 1992 through 1998)
|
|
|
18
|
63016
|
Damper kit, 22.5" Bar-B-Kettle & Smokey Mountain Cooker
|
|
|
19
|
87503
|
Hex nut 1/4-20 inch, zinc
|
|
|
20
|
87403
|
1/4" Flat nylon washer, black
|
|
|
21
|
4086938
|
Hexhead bolt 1/4-20 x 1 3/4 inch
|
|
|
22
|
85730
|
Cart handle for Ranch Kettle, Painted
|
|
|
23
|
99835
|
Tool holder (qty. 1)
|
|
|
24
|
87417
|
Aluminum tubing plug for Ranch Kettle
|
|
|
25
|
87413
|
Hex head screw 5/16-18 x 7/8 inch, black
|
|
|
26
|
85702
|
Ash catcher for the Ranch Kettle, enameled
|
|
|
27
|
64937
|
Top frame for Ranch Kettle, Painted
|
|
|
28
|
87410
|
Hex head screw, 1/4-20 x 3 inch, black
|
|
|
29
|
85931
|
Lid tab for Ranch Kettle, black anodized
|
|
|
30
|
4086928
|
Tubing plug, black
|
|
|
31
|
85930
|
Support strap for Ranch Kettle, black anodized
|
|
|
32
|
85760
|
Tuck-Away frame support for Ranch Kettle, Painted
|
|
|
33
|
64797
|
Bottom frame for Ranch Kettle, Painted
|
|
|
35
|
65936
|
Caster w/insert, qty. 1
|
|
|
36
|
85725
|
Axle for Ranch Kettle 32.37"
|
|
|
37
|
80735
|
8" wheel w/insert and hardware
|
Shop Now$16.99
|
|
37
|
63050
|
Wheel, 8" diameter
|
|
|
38
|
987101
|
Replacement hubcaps (pack of 3)
|
|
|
410
|
57884
|
Charcoal Owners Guide USA '15
|
|
|
410
|
56693
|
Instruction sheet, Ranch '10
|
|
|
470
|
87430
|
Hardware bag for Ranch Kettle
|
|
|
480
|
40260301
|
Handle kit w/o shield, 6" gray
|
|
|
480
|
63016
|
Damper kit, 22.5" Bar-B-Kettle & Smokey Mountain Cooker
|
|
|
510
|
7478
|
Kettle Tool Hook Handle
|
Shop Now$13.49
|
