A
|
8601901
|
Owners manual for Genesis 5000 Gas Grill with liquid propane tank. USA. 1995-1997.
|
|
|
1
|
78970
|
Self-threading nut
|
|
|
1D
|
80158
|
Shroud hardware for year 2000 lid assembly with stud design.
|
|
|
1L
|
80159
|
Hardware pack for year 2000 lid and handle assembly with stud design/rotisserie bracket
|
|
|
1
|
60582
|
Lid assembly, Genesis/Spirit, black
|
|
|
1I
|
4086950
|
Screw #8-32x3/8 inch hex head.
|
|
|
1
|
60542
|
Lid assembly, Genesis B, mica black, SS handle
|
|
|
1
|
97785
|
Hardware for lid handle for Silver B-C,Genesis, Spirit, and Platinum Gas Grills.
|
|
|
1F
|
90501
|
Weber logo label and fasteners
|
|
|
2
|
80632
|
Warm-up basket, '10
|
Shop Now$43.99
|
|
3
|
80633
|
Warming rack, Silver/Gold/Plat B/C/Spirit 300 series
|
Shop Now$43.99
|
|
5
|
48968080
|
Smoker flue, enameled - discontinued
|
|
|
7
|
9813
|
Porcelain enamel flavorizer bars for Genesis series grills.
|
|
|
8
|
9813
|
Porcelain enamel flavorizer bars for Genesis series grills.
|
|
|
9
|
1174100
|
Porcelain enameled cooking grate, Genesis Jr. & also used with smoker attachment (Qty 1)
|
|
|
9
|
9866
|
Porcelain enameled cooking grates, Genesis 4-5000 series (Qty 2)
|
|
|
10
|
9866
|
Porcelain enameled cooking grates, Genesis 4-5000 series (Qty 2)
|
|
|
14
|
4086928
|
Tubing plug, black
|
|
|
15
|
4086974
|
Hexhead bolt 1/4-20 x 2 inch. Black.
|
|
|
22
|
4086958
|
Hexhead screw (bolt) 1/4-20 x 1/2 inch. Black.
|
|
|
24B
|
85911
|
Support rod for Genesis 2-5500 for swing table assembly.
|
|
|
24A
|
4886971
|
Slide lock swing-up table (qty. 1)
|
|
|
24
|
86215
|
Hardware for slide bar 1 side, Genesis 1000-5000 Gas Grills.
|
|
|
27
|
65936
|
Caster w/insert, qty. 1
|
|
|
28
|
99253
|
Catch pan holder (packaged)
|
Shop Now$22.99
|
|
29A
|
93305
|
Aluminum catch pan kit
|
Shop Now$13.99
|
|
30D
|
4986979
|
Screw, 6-32 x 1/4, philips head black
|
|
|
31D
|
4986979
|
Screw, 6-32 x 1/4, philips head black
|
|
|
34
|
987101
|
Replacement hubcaps (pack of 3)
|
|
|
35
|
63050
|
Wheel, 8" diameter
|
|
|
39A
|
4038590
|
Label for the tank scale.
|
|
|
40
|
87503
|
Hex nut 1/4-20 inch, zinc
|
|
|
42
|
4786980
|
Side burner lock
|
|
|
43D
|
41441
|
1/4 pushnut
|
|
|
43C
|
4086927
|
Discontinued - Tank glide wheel for tank scale assembly.
|
|
|
45
|
4086955
|
Hexhead bolt 1/4-20 x 1-1/2 inch.
|
|
|
46A
|
4886971
|
Slide lock swing-up table (qty. 1)
|
|
|
46
|
86215
|
Hardware for slide bar 1 side, Genesis 1000-5000 Gas Grills.
|
|
|
47
|
4886969
|
Screw 10-24 x 1-3/4 inch.
|
|
|
47
|
86901
|
10/24-inch hexagonal nut
|
|
|
48
|
80158
|
Shroud hardware for year 2000 lid assembly with stud design.
|
|
|
49
|
80158
|
Shroud hardware for year 2000 lid assembly with stud design.
|
|
|
50
|
62538
|
Thermometer, dual-purpose.
|
Shop Now$9.99
|
|
51
|
1309
|
Hex nut 1/4 x 20 inch Keps nut
|
|
|
52A
|
97783
|
Bottom tray rails w/hardware
|
|
|
53
|
67672
|
Control knob kit (qty 3)
|
Shop Now$35.99
|
|
56
|
20428
|
Burner tube kit, Genesis 1-5500, Platinum, Genesis Gold 2000-2001, Genesis Platinum
|
Shop Now$77.99
|
|
57
|
20428
|
Burner tube kit, Genesis 1-5500, Platinum, Genesis Gold 2000-2001, Genesis Platinum
|
Shop Now$77.99
|
|
58
|
20428
|
Burner tube kit, Genesis 1-5500, Platinum, Genesis Gold 2000-2001, Genesis Platinum
|
Shop Now$77.99
|
|
60
|
4089600
|
Manifold bracket for Genesis and Platinum series gas grills
|
|
|
62
|
99835
|
Tool holder (qty. 1)
|
|
|
64A
|
48826420
|
Igniter switch (includes push button)
|
|
|
64F
|
70643
|
Ignition chamber assembly, 02
|
|
|
64
|
900
|
Igniter kit for Genesis, Spirit and Platinum model year 2000 grills.
|
Shop Now$18.99
|
|
64C
|
40826414
|
Igniter installation nut.
|
|
|
64B
|
62641
|
Washer, steel, for igniter.
|
|
|
66
|
97786
|
Manifold hardware for Genesis, Spirit, and Platinum Gas Grills.
|
|
|
67
|
99243
|
Tank scale
|
|
|
68
|
87901
|
Wing nut 1/4-20 inch. Black.
|
|
|
70
|
92510
|
Rocker switch. Grey. (1996-present).
|
|
|
71
|
668
|
Control panel plugs with screws. 1/4-inch.
|
|
|
72
|
6021713
|
NUT M8 X 1 HEX BRASS
|
|
|
73
|
6415
|
Aluminum drip pans - small (10 pack)
|
Shop Now$10.99
|
|
410
|
50783
|
Instruction sheet. Fuel scale assembly.
|
|
|
410
|
63335
|
Instruction sheet. Quick disconnect hose and regulator replacement.
|
|
|
410
|
4736910
|
Instruction sheet for adding the Side burner.
|
|
|
410
|
39919
|
Instruction sheet for flamecheck installation/maintenance.
|
|
|
410
|
55355
|
Instruction sheet for burner tube replacement, `02
|
|
|
410
|
97029
|
Instruction sheet for smoker for Summit 400-675
|
|
|
410
|
39906
|
Instruction sheet for ignition chamber.
|
|
|
410
|
55354
|
Instruction Sheet QCC1 Hose Replacement
|
|
|
410
|
96276
|
Instruction sheet for adding a swing up table to the left or right-hand side.
|
|
|
410
|
8601901
|
Owners manual for Genesis 5000 Gas Grill with liquid propane tank. USA. 1995-1997.
|
|
|
460
|
33001
|
End bracket for swing table manufactured in 1993 through 1998.
|
|
|
460
|
80159
|
Hardware pack for year 2000 lid and handle assembly with stud design/rotisserie bracket
|
|
|
460
|
3627
|
Durawood work table with spacer bracket
|
|
|
460
|
63180
|
Spacer bracket. Painted.
|
|
|
460
|
97785
|
Hardware for lid handle for Silver B-C,Genesis, Spirit, and Platinum Gas Grills.
|
|
|
460
|
3626
|
Discontinued - Durawood swing table with hardware, LHS
|
|
|
460
|
62619
|
Instruction sheet for Durawood spacer.
|
|
|
460
|
86215
|
Hardware for slide bar 1 side, Genesis 1000-5000 Gas Grills.
|
|
|
470
|
80159
|
Hardware pack for year 2000 lid and handle assembly with stud design/rotisserie bracket
|
|
|
470
|
97786
|
Manifold hardware for Genesis, Spirit, and Platinum Gas Grills.
|
|
|
470
|
80158
|
Shroud hardware for year 2000 lid assembly with stud design.
|
|
|
470
|
97785
|
Hardware for lid handle for Silver B-C,Genesis, Spirit, and Platinum Gas Grills.
|
|
|
470
|
668
|
Control panel plugs with screws. 1/4-inch.
|
|
|
470
|
97783
|
Bottom tray rails w/hardware
|
|
|
475
|
65570
|
QCC1 Hose & Regulator LP, 21"
|
Shop Now$35.99
|
|
480
|
20428
|
Burner tube kit, Genesis 1-5500, Platinum, Genesis Gold 2000-2001, Genesis Platinum
|
Shop Now$77.99
|
|
480
|
900
|
Igniter kit for Genesis, Spirit and Platinum model year 2000 grills.
|
Shop Now$18.99
|
|
490
|
9861
|
SS cooking grates, Genesis 4-5500/Platinum B-C
|
|
|
490
|
1174100
|
Porcelain enameled cooking grate, Genesis Jr. & also used with smoker attachment (Qty 1)
|
|
|
490
|
7639
|
Stainless steel rod cooking grates, 7mm, (Qty 2)
|
Shop Now$135.99
|
|
490
|
65906
|
Porcelain enameled steel cooking grates, (Qty 2)
|
Shop Now$56.99
|
|
490
|
7638
|
Porcelain enameled cast iron cooking grates, (Qty 2)
|
|
|
490
|
9866
|
Porcelain enameled cooking grates, Genesis 4-5000 series (Qty 2)
|
|
|
495
|
9813
|
Porcelain enamel flavorizer bars for Genesis series grills.
|
|
|
495
|
7538
|
Set of stainless steel flavorizer bars for Genesis series grill
|
Shop Now$114.99
|
|
510
|
62104
|
Weber Grill Out Handle Light - Rectangle Bracket
|
|
|
510
|
80632
|
Warm-up basket, '10
|
Shop Now$43.99
|
|
515
|
47875600
|
Control knob (grey) for the Side burner.
|
|
|
515
|
4736910
|
Instruction sheet for adding the Side burner.
|
|
|
516
|
4786952
|
Fastener, Tinnerman.
|
|
|
516
|
86915
|
Screw #10 x 3/4 Phillips Pan Head
|
|
|
517
|
92510
|
Rocker switch. Grey. (1996-present).
|
|
|
518
|
47997815
|
Bottom Sideburner, black. Two-slot.
|
|
|
521
|
48826420
|
Igniter switch (includes push button)
|
|
|
521
|
63117
|
Igniter kit for the Sideburner.
|
|
|
522
|
40826418
|
Igniter rubber washer
|
|
|
522
|
63117
|
Igniter kit for the Sideburner.
|
|
|
523
|
63117
|
Igniter kit for the Sideburner.
|
|
|
523
|
40826414
|
Igniter installation nut.
|
|
|
525
|
4786955
|
Plastic hinge for side burner cover. Black. (Qty 1)
|
|
|
528
|
4786980
|
Side burner lock
|
|
|
529
|
4786971
|
Spider guard for the Side burner.
|
|
|
531
|
63117
|
Igniter kit for the Sideburner.
|
|
|
531
|
47826421
|
Igniter electrode for the Side burner.
|
|
|
533
|
63117
|
Igniter kit for the Sideburner.
|
|
