A
|
38051
|
Owners manual, 6 burner Summit NG, Canada
|
|
E
|
42775
|
Hardware kit, Summit Platinum, stainless steel
|
|
A
|
38004
|
Assembly guide for 6 burner Summit Gold/Platinum
|
|
B
|
60502
|
Canadian cookbook for Genesis Silver, Gold, Platinum grills, `02
|
|
A
|
38075
|
Literature kit, 6 burner Summit NG, Canada
|
|
1
|
88206
|
Hardware for lid assembly
|
|
2
|
67088
|
Thermometer, '18
|
|
2
|
60393
|
Thermometer w/o tab
|
|
3
|
67717
|
Bezel for Genesis/Summit, '07
|
|
4
|
41737
|
Swing-up basket for Summit, stainless steel
|
|
6
|
41813
|
Smoker assembly for Summit Silver/Gold/Platinum
|
|
8
|
9899
|
Set of flavorizer bars for 6 burner Summit D
|
|
9
|
91486
|
Hardware for Summit rotisserie, includes forks
|
|
10
|
65579
|
Rotisserie motor, Type B, '15
|
|
11
|
66865
|
Bracket for motor w/hardware
|
|
13
|
96975
|
Nut 1/4-20 inch, black zinc.
|
|
14
|
84106
|
Flat washer, 1/4", nylon, natural
|
|
14
|
85973
|
Bolt, 1/4-20 for manifold, stainless steel
|
|
15
|
97438
|
1/4-20 hex nut, stainless steel
|
|
16
|
42326
|
Igniter kit for Summit Gold D/D6
|
|
17
|
42326
|
Igniter kit for Summit Gold D/D6
|
|
18
|
85663
|
Burner tube kit, Summit 6 burner Gold/Platinum D
|
|
19
|
85663
|
Burner tube kit, Summit 6 burner Gold/Platinum D
|
|
20
|
85663
|
Burner tube kit, Summit 6 burner Gold/Platinum D
|
|
21
|
85663
|
Burner tube kit, Summit 6 burner Gold/Platinum D
|
|
22
|
42542
|
Screw, 1/4-20x1/2 phillips trushead, black
|
|
24
|
42326
|
Igniter kit for Summit Gold D/D6
|
|
25
|
42326
|
Igniter kit for Summit Gold D/D6
|
|
26
|
42326
|
Igniter kit for Summit Gold D/D6
|
|
27
|
42326
|
Igniter kit for Summit Gold D/D6
|
|
27
|
42053
|
Ignition switch, red button, for Summit Silver/Gold
|
|
28
|
84107
|
Plastic washer, natural, for control panel and mounting bracket
|
|
28
|
60875
|
10-24x1/2 screw, stainless steel
|
|
29
|
42773
|
Control knob, Summit Platinum, small
|
|
30
|
42772
|
Control knob, Summit Platinum, large
|
|
31
|
41703
|
Mounting clip for control panel
|
|
32
|
42118
|
Ignition decal for front panel
|
|
32
|
82666
|
Front panel, Summit Gold
|
|
35
|
196
|
Hardware for trim pieces
|
|
36
|
84106
|
Flat washer, 1/4", nylon, natural
|
|
37
|
60775
|
1/4-20 x 1/2 hexhead bolt, stainless steel
|
|
38
|
60475
|
Bracket for LHS swing table
|
|
41
|
99240
|
Door plugs and bushings
|
|
42
|
82700
|
Bottom panel, Summit Platinum 6 burner, '05
|
|
43
|
67762
|
Hardware kit for bottom panel
|
|
44
|
99241
|
Caster w/insert
|
|
45
|
60465
|
LHS door replacement, Summit 6 burner, '05
|
|
46
|
81495
|
Screw 10-16x.750, philips pan head sems
|
|
47
|
4086935
|
Plastic plug for control panel, .250
|
|
48
|
43849
|
Door handles w/screws, stainless steel
|
|
49
|
60464
|
RHS door replacement, Summit 6 burner, '05
|
|
50
|
88206
|
Hardware for lid assembly
|
|
51
|
82702
|
Logo replacement, Summit Platinum, '05
|
|
51
|
82692
|
Lid assembly, Summit Platinum D6, SS, '05
|
|
52
|
60873
|
1/4 stainless steel washer
|
|
52
|
84102
|
Hexhead screw, 1/4-20 x 3.25, SS
|
|
54
|
42587
|
10-24 x 1/2 hex head screw, stainless steel, for IR burner
|
|
54
|
42540
|
Flat washer for infrared burner, Summit Gold D
|
|
54
|
96575
|
Hardware kit for cover box, IR burner, Summit Gold D
|
|
55
|
9899
|
Set of flavorizer bars for 6 burner Summit D
|
|
56
|
42763
|
Rain cover for IR burner, Summit Platinum 6 burner
|
|
56
|
96575
|
Hardware kit for cover box, IR burner, Summit Gold D
|
|
57
|
96575
|
Hardware kit for cover box, IR burner, Summit Gold D
|
|
57
|
42587
|
10-24 x 1/2 hex head screw, stainless steel, for IR burner
|
|
59
|
91486
|
Hardware for Summit rotisserie, includes forks
|
|
60
|
82611
|
Infrared burner for natural gas Summit, 6 burner
|
|
60
|
42115
|
Orifice for NG IR burner, 1.45 mm
|
|
61
|
70338
|
Cover box for IR burner
|
|
62
|
42531
|
Wire wrap for IR burner
|
|
62
|
42111
|
Thermocouple for Summit Gold D, copper
|
|
62
|
6021713
|
NUT M8 X 1 HEX BRASS
|
|
63
|
42113
|
Infrared gas line tubing for Summit Gold D
|
|
64
|
63053
|
Rotisserie shaft, 36" Summit '10
|
|
65
|
42326
|
Igniter kit for Summit Gold D/D6
|
|
65
|
43744
|
Hex nut, 1/8-27, brass
|
|
65
|
42112
|
Discontinued - IR electrode w/fasteners
|
|
66
|
82709
|
Cookbox for Summit Platinum D6, '05
|
|
67
|
42326
|
Igniter kit for Summit Gold D/D6
|
|
68
|
42326
|
Igniter kit for Summit Gold D/D6
|
|
69
|
42244
|
Heat shield, Summit Gold
|
|
69
|
42181
|
Wire snap clip for Summit Silver/Gold, hi-temp
|
|
71
|
42326
|
Igniter kit for Summit Gold D/D6
|
|
72
|
84110
|
Wing nut, 10-24, type D, stainless steel
|
|
72
|
84107
|
Plastic washer, natural, for control panel and mounting bracket
|
|
72
|
82596
|
Bulkhead assembly, Summit Platinum NG w/side burner, 1/2"
|
|
73
|
42057
|
Corrugated LP/NG gas line for Summit Silver/Gold, stainless steel
|
|
74
|
42550
|
Natural gas hose with quick-disconnects for Summit, 1/2 inch
|
|
74
|
42144
|
1/2" Quick disconnect fitting
|
|
77
|
6498
|
Drip pan (qty 10) Large Grills
|
|
78
|
70379
|
Catch pan kit
|
|
84
|
987101
|
Replacement hubcaps (pack of 3)
|
|
85
|
82712
|
Right trim, Summit Platinum B/C/D, '05
|
|
86
|
60476
|
Bracket for RHS swing table
|
|
87
|
80313
|
Tank glide buttons
|
|
88
|
82759
|
Door stop, Summit, SS
|
|
89
|
99240
|
Door plugs and bushings
|
|
90
|
78714
|
Hinge rod for Summit doors, '05
|
|
91
|
42040
|
Match holder
|
|
410
|
38051
|
Owners manual, 6 burner Summit NG, Canada
|
|
410
|
38004
|
Assembly guide for 6 burner Summit Gold/Platinum
|
|
410
|
60502
|
Canadian cookbook for Genesis Silver, Gold, Platinum grills, `02
|
|
410
|
38075
|
Literature kit, 6 burner Summit NG, Canada
|
|
470
|
42775
|
Hardware kit, Summit Platinum, stainless steel
|
|
470
|
96575
|
Hardware kit for cover box, IR burner, Summit Gold D
|
|
470
|
80313
|
Tank glide buttons
|
|
480
|
42326
|
Igniter kit for Summit Gold D/D6
|
|
510
|
7516
|
Weber Handle Light, 2015-2019
|
